Digital Earth Leakage Relay, Panel Mount: SELEC ELR341-1

Description Digital Earth Leakage Relay, Panel Mount: SELEC ELR341-1 Detects Leakage current for 1Ø & 3Ø systems Range: 30mA to 30A 1 C / O (SPDT) Relay output Supply voltage of 90 – 270V AC/DC Test and Reset Function via Front / Remote DIN-rail mounting CE Certified Brief Specifications Measuring Parameter Monitors True RMS Earth Leakage Current (upto 30A ) Electrical Connection 1Ø-2W, 3Ø-4W, 3Ø-3W Supply Voltage 90 – 270V AC/DC Trip Leakage current range 30mA – 30A Display Current range 15mA – 33A Time Ranges 0 to 999 sec Response time < 30ms (if trip current 5 x set value & Instantaneous trip is ON), < 50ms (if trip current = 1 x set value) CBCT DETECTION Yes, when CBCT absent or short Accuracy ± 5% setting of current, ± 5% time setting for ±100ms Output Contact 1 C / O (SPDT ) Output Rating NO / 5A@250V AC / 28V DC Size 96X96mm Mounting Type Panel mount Product Variants Product Code Supply Voltage Certification ELR341-1 90 to 270V AC / DC –
